1. Different colors of housing available for selection.

2. Use of high-quality aluminum housing, idea for fast heat dissipation. With protection grade: IP66.

3. The grouping arrangement of IR Leds is studied carefully & precisely, in order to avoid “black corner” effect of image.

4. Patented design of infrared light circuitry, low power consumption less than 40% compared with similar products, no high temperature and longer  life time.

5. Number of LEDs: 14pcs.

6. Horizontal resolution: 420TVL.

7.Small lens 3.6/6/8mm.

8. Auto white balance,auto gain control and back light compensation.

9. 1 meter length cable with high quality BNC connector and DC power jack for easy installation.

Image Sensor :	Sony 1/3 CCD
System :	NTSC / PAL
Number of Pixels :	NTSC:537(H) x 505(V) PAL:537(H) x 597(V)
Picture Elements :	NTSC:510(H) x 492(V) PAL:500(H) x 582(V)
Image Signal Process :	Digital Signal Processing System
Dimension :
Horizontal Resolution :	420TVL
Scanning System :	2:1 Interlace
Min. Illumination :	0 Lux / F1.2( IR ON ) 0.1Lux / F1.2
S/N Ratio :	48dB
Synchronization :	Internal
Electronic Shutter :	Auto - NTSC:1/60S -1/100000S); PAL:(1/50S--1/100000S)
Auto Gain Control :	Auto
White Balance Control :	Auto
Back Light Compensation :	Auto
Lens :	Small Lens 3.6/6/8mm
Day & Night Mode :	Day Color / Night BW
Video Output :	1.0V p-p Composite Video Output - 75ohm
Sense Up :	---
H/V Mirror Function :	---
Color Bar :	---
Auto Aperture Drive :	---
Power Supply :	DC12V
Power Consumption :
Operating Temp :	-10℃～+50℃
Gross Weight :
Packing Dimension :
IR-CUT Filter :	---
OSD Function :	---
Numbers of LEDs :	14pcs Φ5mm IR LED
