1. Transmission distance up to 300m without the need of power supply (passive transceivers).

2. Real-time transmission of AV signals with high-quality of video images.

3. If used with an active (power required) receiver, the transmission range can be extended to 600 meters.

4. High safety performance with Interference suppression. Anti-Lightning grade: 3, fire-resistant and high temperature tolerant.

5. A wide range of applications.

Compatible with :	All Baseband Signals,including PAL, NTSC, SECAM
Transmitting Band :	0-6MHz
Transmission Distance :	300m
Interference Rejection :	more than 60dB
Video Connector :	16 BNC-F
UTP Cable Connector :	RJ-45 jack or Screw terminals
Video Input Protection (as transmitter)   :	2KV(common mode),IEC61000-4-5/1955(GB/T 17626.5-1999)
Video Output Protection (as transmitter) :	2KV(different mode), 4KV(common mode),IEC61000-4-5/1955(GB/T 17626.5-1999)
MTBF :	more than 10,000h
Dimensions (LWH) :	430*100*44.5mm
Housing Material :	Metal
Unit Color :	Black
Net Weight :	1250g
Operating Temperature :	0°C ~55°C
Humidity(non-condensing) :	0~95%
Storage Temperature :	-20°C~80°C
Casing Volume(LWH) :	530*107*70mm
